Choosing the right shower door starts with accurate measurements. Whether you're replacing an old shower door or completing a new bathroom remodel, measuring your shower opening correctly can help you avoid ordering the wrong size and make installation much easier.
Shower doors are available in different styles, including frameless, sliding, and hinged designs. Each type can have different measurement and clearance requirements, so it's important to understand your shower layout before choosing a door.
In this guide, we'll show you how to measure for a shower door step by step and explain what measurements you should check before placing an order.
Before You Start: What You'll Need
You don't need many tools to measure a shower opening. Prepare:
- A tape measure
- A pencil or pen
- Paper or your phone to record measurements
- A level, if available
- A helper for wider shower openings
For better accuracy, measure each dimension more than once and record the measurements in inches.
Step 1: Measure the Width of the Shower Opening
The first and most important measurement is the width of your shower opening.
Measure the distance between the two finished walls where the shower door will be installed.
For the most accurate measurement, measure the width at three different heights:
- Near the bottom of the opening
- Around the middle
- Near the top of the opening
Record all three measurements.
For example:
Bottom: 58 1/2 inches
Middle: 58 3/8 inches
Top: 58 1/4 inches
If the measurements are slightly different, don't simply assume the largest or smallest number is correct. Check the installation instructions for the specific shower door you're considering to determine the acceptable adjustment range.
This is especially important for frameless shower doors because accurate installation dimensions can affect how the glass and hardware fit within the opening.
Step 2: Measure the Height
Next, measure the height of the shower opening.
Measure from the finished shower floor or threshold to the point where the top of the shower door will be installed.
If your shower has a raised threshold, measure from the top surface of the threshold rather than from the bathroom floor.
Also check whether your chosen shower door has a fixed height or an adjustable installation range.
For example, a shower door advertised as 70 inches tall may require a specific finished opening height. Always compare your measurement with the manufacturer's specifications before ordering.
Step 3: Check Whether the Walls Are Level
Your shower walls may look straight but still have slight variations.
Use a level to check both sides of the shower opening.
If the walls are not perfectly plumb, look for a shower door that provides some wall adjustment.
Some shower door systems are designed to accommodate a limited amount of unevenness, while others require more precise wall conditions.
This is particularly important for frameless designs because the glass panels and hardware need to be properly aligned during installation.
Step 4: Measure the Threshold
The shower threshold is another measurement you should not overlook.
Measure the available threshold width where the shower door will be mounted.
Some shower doors require a minimum threshold width to properly support the door hardware or installation components.
Before purchasing, check the manufacturer's installation requirements for:
- Minimum threshold width
- Door mounting requirements
- Wall conditions
- Required clearance
- Hardware placement
A correct opening width alone does not guarantee that a shower door will fit your shower.
Step 5: Check the Door Swing Clearance
If you're installing a hinged shower door, you need to check the space around the door.
Open the door's expected swing path and make sure it will not hit:
- A toilet
- Bathroom vanity
- Wall
- Towel bar
- Cabinet
- Other bathroom fixtures
Hinged shower doors generally require more clearance than sliding doors because the door panel needs space to swing open.
If your bathroom has limited floor space, a sliding shower door may be a better option because the door panels move along a track instead of swinging into the bathroom.
Step 6: Consider Your Shower Door Type
Your measurements can also help determine which type of shower door is appropriate for your bathroom.
Frameless Shower Doors
Frameless shower doors are popular for modern bathrooms because they provide a clean, minimalist appearance with less visible framing.
When measuring for a frameless shower door, pay close attention to the exact finished opening dimensions, wall conditions, threshold, and hardware requirements.
Frameless systems can have specific installation requirements, so always compare your measurements with the product's listed specifications.
Sliding Shower Doors
Sliding shower doors can be a practical solution when you don't have enough space for a swinging door.
When measuring for a sliding shower door, measure the full shower opening width and check the required wall and track dimensions.
Also consider how much of the opening will be available as a walk-in entrance once the sliding panels are installed.
Hinged Shower Doors
Hinged shower doors can provide a wide and comfortable entrance, but they require enough clearance for the door to swing.
Measure both the shower opening and the surrounding bathroom area before ordering.
Make sure the door can open fully without contacting another fixture or wall.
Step 7: Measure Existing Shower Openings Carefully
If you're replacing an existing shower door, don't rely only on the dimensions of your old door.
The listed size of an existing shower door may not be the same as the actual finished opening.
Instead, measure the finished shower opening itself.
For example, if your existing door is labeled as a "60-inch shower door," your actual wall-to-wall opening may be slightly different.
Always use the finished opening measurements and compare them with the new product's installation range.
Step 8: Record Your Measurements
After measuring, write down all of your dimensions.
A simple measurement chart can help:
| Measurement | Your Size |
|---|---|
| Opening Width - Bottom | ____ in |
| Opening Width - Middle | ____ in |
| Opening Width - Top | ____ in |
| Opening Height | ____ in |
| Threshold Width | ____ in |
| Available Door Clearance | ____ in |
Keeping these measurements together makes it easier to compare different shower door options.
Step 9: Compare Your Measurements With the Product Specifications
This is one of the most important steps.
Before purchasing a shower door, compare your measurements with the manufacturer's listed dimensions.
Look for information such as:
- Fits opening width
- Door height
- Walk-in opening
- Wall adjustment
- Minimum threshold
- Door swing requirements
- Installation configuration
- Reversible installation, if applicable
For example, a shower door listed as fitting a range of opening widths may allow some adjustment during installation. However, your actual opening must still fall within the manufacturer's specified range.
Never assume that a product will fit simply because the advertised size looks similar to your shower opening.
Common Shower Door Measuring Mistakes to Avoid
Measuring Only Once
Walls and shower surfaces are not always perfectly straight. Measuring at multiple points helps identify differences in the opening.
Measuring the Old Door Instead of the Opening
The old door's dimensions do not necessarily represent your finished shower opening. Measure the wall-to-wall opening instead.
Forgetting Door Clearance
A hinged door may fit the shower opening but still hit a vanity or toilet when opened.
Always check the entire swing path.
Ignoring the Threshold
A shower door may require a certain minimum threshold width for installation. Check this measurement before ordering.
Not Checking the Installation Range
A product's advertised size is not always its exact finished opening requirement. Always check the specified installation range.
Frequently Asked Questions
How do I measure for a shower door?
Measure the finished shower opening width at the bottom, middle, and top. Then measure the opening height, threshold width, and available clearance around the shower.
Should I measure the shower door or the shower opening?
Measure the finished shower opening rather than the existing door. The actual opening dimensions are what you should compare with the new shower door's installation specifications.
How many times should I measure my shower opening?
For the width, measure at least three points—bottom, middle, and top. This helps identify walls that are not perfectly parallel.
What type of shower door is best for a small bathroom?
Sliding shower doors can be a practical choice for smaller bathrooms because they don't require the same swing clearance as hinged doors. However, the best option depends on your specific layout and available opening.
Do frameless shower doors require precise measurements?
Yes. Frameless shower doors can have specific glass, hardware, wall, and threshold requirements, so accurate measurements are important before ordering.
Final Thoughts
Accurate measurements are one of the most important steps when choosing a shower door. By measuring the opening at multiple points, checking the height and threshold, evaluating wall conditions, and considering door clearance, you can narrow down your options with greater confidence.
Once you know your measurements, the next step is choosing the right style for your bathroom.
If you're still deciding between different designs, read our guide [How to Choose the Right Shower Door for Your Bathroom] to compare frameless, sliding, and hinged shower doors and learn which style may work best for different bathroom layouts.
